.103 FLUOROELASTOMER Q-RING CORD

This quad-ring cord stock is supplied in black Viton® (FKM) 75 Shore A measuring a cross section of 0.103 in (2.62 mm), catalogued under part number 0Q283103. It lets you fabricate a quad-ring seal to any circumference without a special tooling charge.

This material stands up to chlorinated solvents, engine and transmission fluids, and petroleum oils and fuels. Viton® (FKM) is widely chosen for long service life in hot, chemically aggressive environments and very low compression set at elevated temperature. Verify compatibility before use with hot water and steam or low-molecular-weight organic acids. The profile itself contributes two sealing bands per contact face rather than one and a parting line located away from the sealing surface.

Common environments for this compound include aerospace, semiconductor equipment, and high-temperature process equipment.

0Q283103 ships by the foot. Application requirements vary, so validate compatibility with your process conditions prior to installation.
