2103-159 PTFE S/T BUP FDA

This back-up ring is supplied in AS568-159 white PTFE (Teflon) 55 Shore D with an inside diameter of 4.987 in (126.67 mm), a cross section of 0.103 in (2.62 mm), and an outside diameter of 5.193 in (131.9 mm), catalogued under part number TST159. It installs on the low-pressure side of an o-ring to prevent extrusion into the clearance gap at elevated pressure.

This material stands up to strong acids and bases, oxidizing media, and steam. That behavior comes from the compound itself: PTFE (Teflon) delivers a very wide continuous service temperature range and non-stick, non-contaminating surface characteristics. Service temperature is rated from -65°F (-53.9°C) through 500°F (260°C). Applications involving elemental fluorine at temperature or molten alkali metals call for a different compound.

You will find this material specified across chemical processing, semiconductor fabrication, and food and beverage.

Order part number TST159, sold individually. Application requirements vary, so validate compatibility with your process conditions prior to installation.
