FASTNER SEAL, STEEL PLATED,

The AFS600-0101-7/8 is a black Buna-N (Nitrile) Thread Seal measuring an inside diameter of 0.875 in (22.23 mm). This thread seal prevents weepage at threaded ports without additional tape or sealant. This item is further identified as Nitrile 70 - 7/8.

Expect good resistance to petroleum-based oils, propane and butane, and hydraulic fluids. Buna-N (Nitrile) delivers low compression set under sustained load, reliable performance in both static and dynamic service. The material carries a published service range of -40°F (-40°C) to 250°F (121.1°C). Exposure to strong acids or polar solvents will shorten service life.

Common environments for this compound include general industrial maintenance, construction equipment, and hydraulic and pneumatic systems.

Order part number AFS600-0101-7/8, sold individually. Check the compound against your process media, pressure and temperature before committing to a design. If you need a size, durometer or compound that is not listed, APG can cross-reference from a print, a sample or a competitor part number.
