2MM CS X 19MM ID BROWN FKM 75D

This o-ring is supplied in brown Viton® (FKM) 75 Shore A measuring an inside diameter of 19 mm (0.748 in), a cross section of 2 mm (0.079 in), and an outside diameter of 23 mm (0.91 in), catalogued under part number VB75M2X19. It seats in a machined groove and forms a leak-tight barrier when compressed between two mating surfaces.

This material stands up to aggressive chemicals, engine and transmission fluids, and petroleum oils and fuels. That behavior comes from the compound itself: Viton® (FKM) is widely chosen for excellent resistance to compression set and permeation, very low compression set at elevated temperature. Service temperature is rated from -15°F (-26.1°C) through 400°F (204.4°C).

You will find this material specified across chemical processing, semiconductor equipment, and aerospace.

Order part number VB75M2X19, sold individually. Unit weight is approximately 0.429 g. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing. APG supports cross-referencing from drawings, samples and competitor numbers when a listed size is not an exact fit.
