5MM CS X 27MM ID BLACK FKM 75D

APG stocks the V5X27, a black Viton® (FKM) 75 Shore A O-Ring built to an inside diameter of 27 mm (1.063 in), a cross section of 5 mm (0.197 in), and an outside diameter of 37 mm (1.46 in). An o-ring compresses into its gland to block fluid or gas migration across a joint.

The material holds up against aromatic hydrocarbons, engine and transmission fluids, and aggressive chemicals. That behavior comes from the compound itself: Viton® (FKM) is widely chosen for outstanding high-temperature capability, excellent resistance to compression set and permeation. Rated temperature range runs from -15°F (-26.1°C) to 400°F (204.4°C) in continuous service. Exposure to amines or low-molecular-weight organic acids will shorten service life.

Typical settings include semiconductor equipment, chemical processing, and oil and gas.

Reference part number V5X27 when ordering; the item is sold individually. Unit weight is approximately 3.598 g. Check the compound against your process media, pressure and temperature before committing to a design. APG supports cross-referencing from drawings, samples and competitor numbers when a listed size is not an exact fit.
