5MM CS X 30MM ID BLACK FKM 75D

This o-ring is supplied in black Viton® (FKM) 75 Shore A measuring an inside diameter of 30 mm (1.181 in), a cross section of 5 mm (0.197 in), and an outside diameter of 40 mm (1.57 in), catalogued under part number V5X30. It seats in a machined groove and forms a leak-tight barrier when compressed between two mating surfaces.

Viton® (FKM) is specified for the industry benchmark where nitrile reaches its thermal limit and long service life in hot, chemically aggressive environments. Expect good resistance to aromatic hydrocarbons, petroleum oils and fuels, and many acids. The material carries a published service range of -15°F (-26.1°C) to 400°F (204.4°C). It is not the right choice where low-molecular-weight organic acids or hot water and steam are present.

It sees regular use in high-temperature process equipment, aerospace, and semiconductor equipment.

Reference part number V5X30 when ordering; the item is sold individually. Unit weight is approximately 3.9425 g. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing.
