1MM CS X 32MM ID BLACK FKM 75D

This o-ring is supplied in black Viton® (FKM) 75 Shore A measuring an inside diameter of 32 mm (1.26 in), a cross section of 1 mm (0.039 in), and an outside diameter of 34 mm (1.34 in), catalogued under part number V1X32. It seats in a machined groove and forms a leak-tight barrier when compressed between two mating surfaces.

Viton® (FKM) is valued for the industry benchmark where nitrile reaches its thermal limit and very low compression set at elevated temperature. Expect good resistance to aromatic hydrocarbons, aggressive chemicals, and chlorinated solvents. Service temperature is rated from -15°F (-26.1°C) through 400°F (204.4°C).

Common environments for this compound include oil and gas, semiconductor equipment, and chemical processing.

V1X32 ships individually. Unit weight is approximately 0.163 g. Application requirements vary, so validate compatibility with your process conditions prior to installation. APG supports cross-referencing from drawings, samples and competitor numbers when a listed size is not an exact fit.
