2MM CS X 51MM ID BLACK FKM 75D

V2X51 is a black Viton® (FKM) 75 Shore A O-Ring measuring an inside diameter of 51 mm (2.008 in), a cross section of 2 mm (0.079 in), and an outside diameter of 55 mm (2.17 in). In service, this o-ring delivers dependable bidirectional sealing in a compact groove envelope.

Viton® (FKM) is specified here for very low compression set at elevated temperature and long service life in hot, chemically aggressive environments. This material stands up to petroleum oils and fuels, chlorinated solvents, and aggressive chemicals. Service temperature is rated from -15°F (-26.1°C) through 400°F (204.4°C). Applications involving ketones and esters or low-molecular-weight organic acids call for a different compound.

Typical settings include high-temperature process equipment, semiconductor equipment, and chemical processing.

Reference part number V2X51 when ordering; the item is sold individually. Unit weight is approximately 0.9714 g. Check the compound against your process media, pressure and temperature before committing to a design. If you need a size, durometer or compound that is not listed, APG can cross-reference from a print, a sample or a competitor part number.
