2MM CS X 75MM ID BLACK FKM 75D

This o-ring is supplied in black Viton® (FKM) 75 Shore A with an inside diameter of 75 mm (2.953 in), a cross section of 2 mm (0.079 in), and an outside diameter of 79 mm (3.11 in), catalogued under part number V2X75. It seats in a machined groove and forms a leak-tight barrier when compressed between two mating surfaces.

Viton® (FKM) delivers excellent resistance to compression set and permeation, outstanding high-temperature capability. The compound resists aromatic hydrocarbons, petroleum oils and fuels, and engine and transmission fluids. Service temperature is rated from -15°F (-26.1°C) through 400°F (204.4°C). It is not the right choice where hot water and steam or amines are present.

Typical settings include automotive fuel systems, aerospace, and chemical processing.

Stocked as V2X75 and sold individually. Unit weight is approximately 1.4508 g. Application requirements vary, so validate compatibility with your process conditions prior to installation. APG supports cross-referencing from drawings, samples and competitor numbers when a listed size is not an exact fit.
