4214-366Y MINNESOTA RUBBER QUAD RING

APG stocks the HQ4214, an AS568-214 black Buna-N (Nitrile) 70 Shore A Quad-Ring measuring an inside diameter of 0.984 in (24.99 mm), a cross section of 0.139 in (3.53 mm), and an outside diameter of 1.262 in (32.05 mm). A quad-ring uses a four-lobed profile to create two sealing surfaces per side, reducing the squeeze needed to seal.

It resists petroleum-based oils, greases and lubricants, and many alcohols. That behavior comes from the compound itself: Buna-N (Nitrile) is known for the most widely specified general-purpose sealing elastomer and an economical choice for high-volume maintenance programs. Published continuous service range is -40°F (-40°C) to 250°F (121.1°C). Applications involving ozone and direct sunlight or ketones call for a different compound. The profile itself contributes lower compressive load required to achieve a seal and two sealing bands per contact face rather than one.

You will find this material specified across construction equipment, hydraulic and pneumatic systems, and general industrial maintenance.

Order part number HQ4214, sold individually. Review your operating media and conditions against this specification before installation. If you need a size, durometer or compound that is not listed, APG can cross-reference from a print, a sample or a competitor part number.
