Q-112 BUNA 70 Q RING

APG stocks the QH70112, an AS568-112 black Buna-N (Nitrile) 70 Shore A Quad-Ring with an inside diameter of 0.487 in (12.37 mm), a cross section of 0.103 in (2.62 mm), and an outside diameter of 0.693 in (17.6 mm). A quad-ring seats in a standard o-ring gland while offering improved dynamic performance.

Buna-N (Nitrile) is known for an economical choice for high-volume maintenance programs and the most widely specified general-purpose sealing elastomer. The material holds up against greases and lubricants, water, and petroleum-based oils. Continuous operating temperature is published at -40°F (-40°C) to 250°F (121.1°C). Verify compatibility before use with polar solvents or ketones. The profile itself contributes two sealing bands per contact face rather than one and a parting line located away from the sealing surface.

Typical settings include automotive, agricultural equipment, and construction equipment.

Stocked as QH70112 and sold individually. Unit weight is approximately 0.3315 g. Review your operating media and conditions against this specification before installation. For a size or compound outside the standard catalog, APG can quote from a print or sample.
