Ordered as TST121, this is an AS568-121 white PTFE (Teflon) 55 Shore D Back-Up Ring measuring an inside diameter of 1.049 in (26.64 mm), a cross section of 0.103 in (2.62 mm), and an outside diameter of 1.255 in (31.88 mm). The back-up ring installs on the low-pressure side of an o-ring to prevent extrusion into the clearance gap at elevated pressure.
PTFE (Teflon) is specified here for very wide continuous service temperature range and non-stick, non-contaminating surface characteristics. This material stands up to solvents, steam, and oxidizing media. Rated temperature range runs from -65°F (-53.9°C) to 500°F (260°C) in continuous service. It should not be specified for service in service requiring elastic recovery or molten alkali metals.
Common environments for this compound include aggressive-media pipelines, pharmaceutical and biotech, and semiconductor fabrication.
Reference part number TST121 when ordering; the item is sold individually. Nominal inside diameter is listed as 1 1/16 inch. As always, verify media compatibility and operating conditions against the requirements of your specific application.
Description -121 WHITE PTFE 55D SINGLE TURN
Actual Cross Section 0.103 inch (2.62 mm)
Actual Inside Diameter 1.049 inch (26.64 mm)
Actual Outside Diameter 1.255 inch (31.88 mm)
Measurement System Imperial
Product Category O-Rings - Backup Rings
