244 PTFE SOLID BACKUP RING FDA

APG stocks the TST244SO, an AS568-244 white PTFE (Teflon) 55 Shore D Back-Up Ring built to an inside diameter of 4.234 in (107.54 mm), a cross section of 0.139 in (3.53 mm), and an outside diameter of 4.512 in (114.6 mm). A back-up ring allows a standard o-ring to operate at higher pressures than it could unsupported.

PTFE (Teflon) is valued for excellent dielectric properties and a very wide continuous service temperature range. Expect good resistance to solvents, steam, and oxidizing media. Service temperature is rated from -65°F (-53.9°C) through 500°F (260°C). Verify compatibility before use with elemental fluorine at temperature or molten alkali metals.

It sees regular use in pharmaceutical and biotech, aggressive-media pipelines, and food and beverage.

Stocked as TST244SO and sold individually. Review your operating media and conditions against this specification before installation. Not finding the exact configuration you need? APG cross-references from prints, samples and competitor part numbers.
