8-224 BLACK FKM 90D BACK-UP RING

Ordered as VBU90224, this is an AS568-224 black Viton® (FKM) 90 Shore A Back-Up Ring built to an inside diameter of 1.734 in (44.04 mm), a cross section of 0.139 in (3.53 mm), and an outside diameter of 2.012 in (51.1 mm). The back-up ring bridges the extrusion gap so the primary seal holds its shape under load.

Viton® (FKM) is specified here for industry benchmark where nitrile reaches its thermal limit and long service life in hot, chemically aggressive environments. This material stands up to many acids, aggressive chemicals, and chlorinated solvents. Rated temperature range runs from -15°F (-26.1°C) to 400°F (204.4°C) in continuous service. It is not the right choice where hot water and steam or amines are present.

You will find this material specified across oil and gas, semiconductor equipment, and aerospace.

VBU90224 ships individually. Unit weight is approximately 0.9233 g and nominal inside diameter is listed as 1 3/4 inch. Application requirements vary, so validate compatibility with your process conditions prior to installation. For a size or compound outside the standard catalog, APG can quote from a print or sample.
